Korg EXB-RADIAS for M3 Owner's manual, Page 54
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
Parameter guide
46
Copy MOD SEQ
This command copies modulation sequence settings from
another RADIAS program to the currently selected RADIAS
program.
1. Choose “Copy MOD SEQ” to access the dialog
box.
2. Use the “Program” field to choose the copy-source
program and modulation sequence.
Choose the program in the upper line, and in the lower line
choose the modulation sequence that you want to copy.
When selecting a program, you’ll only be able to select
from bank INT-F and user program banks whose bank
type is set to RADIAS.
3. Use the “To” field to select the copy-destination
modulation sequence.
4. Press the OK button to execute the copy. If you
decide not to execute, press the Cancel button.
Write Formant Motion Data
This command saves your recorded formant motion data
into internal memory.
Be sure to save important data that you want to keep.
Formant motion data you’ve recorded will be lost if you
select other formant motion data or turn off the power
before you’ve saved it.
1. Choose “Write Formant Motion Data” to access the
dialog box.
2. The upper line shows the formant motion name.
If you want to change the formant motion name, press the
text edit button to access the text edit dialog box, and enter
the desired name.
3. In the “To” field, select the save-destination.
4. Press the OK button to write the formant motion
data. If you decide not to execute, press the Cancel
button.
If you want to save the formant motion data you
recorded, you must write it. If you perform any of the
following actions before writing it, the formant motion
data you recorded will be lost.
• Select other formant motion data.
• Select another program.
•Turn off the power.
• Receive a MIDI dump of the corresponding data from
an external connected device.
Copy Vocoder
This command copies the vocoder setting from the specified
program, combination, or song into the currently selected
RADIAS program.
1. Choose “Copy Vocoder” to access the dialog box.
2. In the “From” field, choose the copy-source.
Select the mode in the upper line, and in the lower line select
the program, combination, or song.
When selecting a program, you’ll only be able to select
from bank INT-F and user program banks whose bank
type is set to RADIAS.
The settings will not change if you execute this
command after selecting a combination or song that
does not use a RADIAS program.
3. Press the OK button to execute the copy. If you
decide not to execute, press the Cancel button.
