Parameter guide
Program mode
Page Select
For details on how to select each page, refer to the “M3
operation guide.”
PROG P0: Play
In this page you can select and play programs. Here you can
also perform simple editing of the drum track, EQ, and
KARMA function, make settings for the audio inputs and
resampling, and view the control surface.
0–1: Main
Here you can select a program and specify the tempo. You
can also specify the drum track pattern, program, and EQ.
These settings are linked with the parameters shown in P1-3,
4, and P4-8.
The screen shows the settings for SW1, SW2, the control
surface, the filters, and EG2 (amp).
For details on the available parameters and menu
commands, refer to the “M3 parameter guide.
0–5: KARMA GE
Here you can make settings for the KARMA function in
Program mode. A RADIAS program can use one KARMA
module (module [A]).
For details on the available parameters and menu
commands, please see “0–5: KARMA GE” on page 4 of the
M3 parameter guide.
0–6: KARMA RTC
Here you can view the names of the KARMA Sliders 1–8
and KARMA Switches 1–8, and the values that are written
to the parameters. The number and value of the GE realtime
parameters and performance realtime parameters controlled
when you operate these controllers is also shown.
For details on the available parameters and menu
commands, please see “0–6: KARMA RTC” on page 6 of the
M3 parameter guide.
Page Main content
PLAY
P0: Play
Select and play RADIAS programs.Simple
KARMA editing.
Audio input settings and resampling
settings.
Editing from the control surface.
(☞M3 PG p.2)
EDIT
P1: Basic/DT/Ctrls
Basic RADIAS program settings, such as voice
assign mode. (☞p.25)
Drum track settings.
X–Y control settings.
SW1, 2, and slider function settings.)
Pad note and velocity settings.
(☞M3 PG p.25)
P2: OSC/Pitch
Oscillator selection and pitch settings.
(☞p.30)
P3: Filter Filter (tone) settings. (☞p.34)
P4: Amp/EQ
Amp (volume) settings. (☞p.37)
Drive/Wave shape settings. (☞p.36)
3-band parametric EQ settings. (☞M3 PG
p.58)
P5: EG,/LFO/M SEQ
EG settings. (☞p.38)
LFO settings. (☞p.39)
Modulation Sequencer settings (☞p.40)
P6: Vocoder Vocoder settings. (☞p.42)
KARMA
P7–1: KARMA1–
GE Setup/Module
Overall settings for KARMA, and settings for
each module. (☞M3 PG p.77)
P7–2: KARMA2–
GE RTP/Perf
KARMA realtime parameter settings and
performance parameter settings. (☞M3 PG
p.90)
EFFECT
P8: IFX
Oscillator output bus and master effect send
level settings.
Insert effect routing, selection, and settings.
(☞M3 PG p.98)
P9: MFX/TFX
Master effect routing, selection, and settings.
Total effect selection and settings. (☞M3 PG
p.103)
