Honda All New Amaze 2018 Manual, Page 311

309
uuFusesuInspecting and Changing Fuses
Handling the Unexpected
Inspecting and Changing Fuses
1. Turn the ignition switch to LOCK (0
*1
. Turn
headlights and all accessories off.
2. Open the cover on the battery + terminal.
3. Check the fuse in the engine compartment
fuse box B.
u If the fuse is blown, have it replace by a
dealer.
4. Open the fuse box cover in the engine
compartment fuse box A.
5. Check the large fuse in the engine
compartment fuse box A.
u If the fuse is blown, use a Phillips-head
screwdriver to remove the screw and
replace it with a new one.
6. Inspect the small fuses in the engine
compartment fuse box A and the vehicle
interior.
u If there is a blown fuse, remove it with
the fuse puller and replace it with a new
one.
*1: Models with the keyless access system have an ENGINE
START/STOP button instead of an ignition switch.
1Inspecting and Changing Fuses
NOTICE
Replacing a fuse with one that has a higher rating
greatly increases the chances of damaging the
electrical system.
Replace fuse with a spare fuse of the same specified
amperage.
Use the charts to locate the fuse in question and
confirm the specified amperage.
2 Fuse Locations P. 303
There is a fuse puller on the back of the engine
compartment fuse box cover.
Blown Fuse
Combined
Fuse
Blown Fuse
Fuse Puller
