Olympus Digital Camera SP-560UZ Instruction Manual and Quick Start Guide, Page 39
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
EN 39
Menu operations
Allows you to specify a part of the movie and overwrite it, or save it as a new movie.
Allows you to capture a still image from the movie, which is taken and record in JPEG format.
This function allows you to save printing data (the number of prints and the date and time
information) with the pictures stored on the card.
g“Print settings (DPOF)” (P.52)
Pictures taken with the camera held vertically are displayed horizontally during playback. This
function allows you to turn such pictures so that they are displayed vertically. New picture
orientations are saved even when the power is turned off.
EDIT ...................................................................................
Extracting a part of the movie
• Select [NEW FILE] or [OVERWRITE], and press o.
• Use the arrow pad to select the first frame of the part you want to
keep, and press o. In the same manner, select the last frame of
the part you want to keep and press o.
MOVIE INDEX .........................................................
Capturing a still image from the movie
• Use 43 to select a movie and press o.
• Use the arrow pad to select the frame to capture, and press o.
6 PRINT ORDER
Making print reservations (DPOF)
7 PLAYBACK MENU
0 ...................................................................................................
Protecting pictures
OFF /ON
Protected pictures cannot be erased with [ERASE]/[SEL. IMAGE]/
[ALL ERASE], but they are all erased by formatting.
• Select the picture with 43, and protect it by selecting [ON] with
12. You can protect several frames in succession. When a
picture is protected, 9 is displayed on the monitor.
y ........................................................................................................
Rotating pictures
+90°/ 0° /–90°
t
he movie
OK
SET
00:00
00:00
/00:36
00:36
g
e from the movie
OK
SET
MENU
BACK
[xD]MOVIE INDEX
a
tions (DPOF)
OK
EXIT
OFF
ON
[IN]
0
