Button operations
16 EN
Shooting mode: Shooting with digital image stabilization
Press h in shooting mode to select [hON].
Press o to set.
g “IMAGE STABILIZER
Shooting pictures using digital image stabilization
” (P.29)
Shooting mode: Using this button as custom button
h allows you to register frequently used functions when the Mode Dial is P, A, S, M, r or s.
(custom button)
You can then set the settings directly with the button instead of displaying the screen from the menu.
(Example) When [FINE ZOOM] is registered in [CUSTOM BUTTON]
Press h n
g “CUSTOM BUTTON
Assigning functions to the custom buttons
” (P.47)
“Functions that can be assigned to My Mode/custom button” (P.72)
5 h /mbutton
Shooting with digital image stabilization/Using this button as custom
button/Playing back continuously shot pictures in index display
z Locking the focus position (AF Lock)
• Assign the AF lock function to h so that the focus is
locked by pressing h, and V (AF lock mark) is
displayed on the monitor. AF Lock will be kept after
shooting. To cancel the AF Lock, either press h
again, or change the exposure/shooting settings or the
shooting mode. Each time you press the button, focus
is locked and canceled alternately.
• If the zoom is operated after engaging the AF lock, the
picture may be out of focus. Engage the AF lock after
operating the zoom.
z Locking the exposure (AE lock)
• Assign the AE lock function to h so that the meter
reading is saved by pressing h and the exposure is
locked. B (AE lock mark) is displayed on the monitor.
AE Lock will be kept after shooting. To cancel the AE
Lock, either press h again, or change the exposure/
shooting settings or the shooting mode.Each time you
press the button, focus is locked and canceled
alternately.
z Locking the focus positions and exposure (AF
LOCK + AE LOCK)
• Register the AF lock + AE lock functions to h so that
the meter reading is saved by pressing h and the
focus and exposure is locked.V(AF lock mark) and
B(AE lock mark) are displayed on the monitor. Press
h again to cancel the AF lock + AE lock. Each time
you press the button, focus and exposure are locked
and canceled alternately.
b
utton as custom button/Playing back
FINE ZOOM
OFF
ON
OK
SET
A direct setting screen is displayed.
AF lock mark
B is displayed while in AE lock.
